iced is cool

Being a racing driver means you are racing with other people. And if you no longer go for a gap that exists, you are no longer a racing driver. – Ayrton Senna

Preface

If you’ve spent any time looking at the Rust GUI landscape, you’ve probably heard of iced. It has quickly become one of the most popular libraries for building native user interfaces in Rust, loved for its type-safety and declarative approach. In fact, it has matured enough to power entire desktop environments: System76 is building their next-generation COSMIC desktop environment completely on top of it.

Lately, I’ve been working on adding a native print dialog to the COSMIC desktop. Working on a project of this scale means getting comfortable with how iced manages state, updates, and asynchronous background tasks.

To consolidate my own learning and give back to the community, I wanted to write about how iced handles asynchronous background work. In this post, we’ll build a very basic system monitor app that tracks CPU usage in real-time. We’ll start with how iced works at a high level and then build the application iteratively, diving deep into Subscriptions - the idiomatic way to handle streaming data in iced.

How does iced work?

If you come from the web world, you’re probably familiar with React, Vue, or Elm. If not, don’t worry. iced is built entirely on the principles of The Elm Architecture (TEA).

Instead of managing mutable UI nodes directly (like in GTK or Qt, where you hold references to widgets and call .set_text() on them), iced is completely declarative. It revolves around a simple, unidirectional loop made of four core concepts:

1. State: The data of your application. For example, cpu_usage: f64.
2. View: A function that describes how your state should be rendered. It takes your state and returns a tree of UI widgets.
3. Message: User interactions or background events that happen in your application (e.g., a button click, or a new CPU stat sample arriving).
4. Update: A function that takes your current State and a Message, updates the state accordingly, and tells iced if we need to run any commands.

Whenever the state changes in the update function, iced automatically calls view again, computes the difference, and redraws the UI.

    graph TD
    State[State] -->|view| View[View]
    View -->|User Action / Event| Message[Message]
    Message -->|update| Update[Update]
    Update -->|Mutates State| State
    Update -.->|Task / Subscription| Async[Async Task / Stream]
    Async -.->|Yields| Message

This makes UI state management deterministic, testable, and incredibly satisfying.

The Target App & The CPU Sampler

To demonstrate this, we’ll build a simple system monitor that queries CPU stats from /proc/stat and shows them using progress bars.

But hold on for a second, reading and parsing /proc/stat requires some OS-level work. Since this tutorial focuses on iced and subscriptions, I won’t go deep into the parsing details here. I’ve written a module cpu.rs using the procfs crate that handles calculating the delta of CPU time ticks. (Find the code here: link)

Here is a quick overview of what the cpu.rs module exposes:

• CpuStats: A struct containing the total CPU usage percentage and a list of per-core percentages:

  pub struct CpuStats {
      pub total: f64, // 0.0..=100.0%
      pub per_core: Vec<f64>,
  }

• CpuSampler: A stateful sampler. Its sample() async method returns the delta calculated as CpuStats compared to the last time it was sampled. Since it needs two data points to compute a delta, the first call to sample() returns None.

With cpu.rs in place, let’s build the app!

Tutorial: Step-by-Step System Monitor

Let’s initialize our project and build our app iteratively. (Full code here: GitHub)

Step 1: The Static Shell (State & View)

First, we need to define our application’s State and describe how to render it. Initially, we won’t have any real CPU stats, so we’ll start with cpu_stats as None (which defaults to 0% usage).

Create src/main.rs:

mod cpu;

use cpu::CpuStats;
use iced::{
    Element,
    Length::Fill,
    Theme,
    widget::{column, progress_bar, text},
};

struct SystemMonitor {
    cpu_stats: Option<CpuStats>,
}

impl SystemMonitor {
    fn new() -> Self {
        Self { cpu_stats: None }
    }

    fn view(&self) -> Element<'_, Message> {
        // Fallback to empty stats if none have been sampled yet
        let cpu_stats = self.cpu_stats.clone().unwrap_or_default();

        column![
            text("Total CPU Usage"),
            progress_bar(0.0..=100.0, cpu_stats.total as f32)
        ]
        .spacing(10)
        .padding(10)
        .into()
    }
}

Wait, what is Message here? And how do we actually run this? Let’s add them in.

Step 2: The Update Loop and running the App

To make the code compile and run, we need to define our Message enum, implement the update logic (which is empty for now), and wire it into the iced::application entry point.

#[derive(Debug, Clone)]
enum Message {
    // We'll receive the sampled stats (or an error string) here
    CpuStatSampled(Result<Option<CpuStats>, String>),
}

fn main() -> iced::Result {
    iced::application(
        SystemMonitor::new,
        SystemMonitor::update,
        SystemMonitor::view,
    )
    .title("System Monitor")
    .run()
}

impl SystemMonitor {
    // ... new and view from Step 1 ...

    fn update(&mut self, message: Message) {
        match message {
            Message::CpuStatSampled(Ok(stats)) => {
                self.cpu_stats = stats;
            }
            Message::CpuStatSampled(Err(e)) => {
                eprintln!("Sampling Error: {e}");
            }
        }
    }
}

If you run cargo run now, you’ll see a window with a static 0% progress bar. It’s clean, but it’s dead. How do we make it tick every second in the background?

Step 3: Enter Subscriptions (Making it Tick)

This is the core topic. A Subscription in iced is a way to listen to external, asynchronous event streams. Unlike a Command (which is a one-off async task, like fetching a single HTTP request), a Subscription stays alive and can yield messages continuously.

We want to poll the CPU stats every second. We can express this as a stream::unfold that encapsulates our CpuSampler and yields a Message on every iteration after sleeping.

Let’s implement our subscription logic:

use std::time::Duration;
use iced::{Subscription, futures::stream};
use cpu::CpuSampler;

fn cpu_subscription() -> Subscription<Message> {
    Subscription::run(cpu_stream)
}

fn cpu_stream() -> impl stream::Stream<Item = Message> {
    stream::unfold(CpuSampler::new(), |mut sampler| async move {
        // Sleep for 1 second before sampling
        tokio::time::sleep(Duration::from_secs(1)).await;

        let result = sampler.sample().await.map_err(|e| e.to_string());

        Some((Message::CpuStatSampled(result), sampler))
    })
}

Let’s analyze what’s going on here:

1. Subscription::run(...) takes a function that returns an asynchronous stream of items. Every time the stream produces a value, it is wrapped as a Message and sent into the update loop.
2. stream::unfold is a beautiful functional utility from the futures crate. It takes an initial state (our CpuSampler) and a closure. The closure performs the async work (sleep and sample) and returns Some((item, next_state)) to continue yielding, or None to terminate.
3. Because stream::unfold threads the sampler back to the next iteration, we preserve the internal state of CpuSampler (which holds the previous tick durations necessary to compute the delta).

Now, we wire this subscription into our application using the .subscription() builder method in main:

fn main() -> iced::Result {
    iced::application(
        SystemMonitor::new,
        SystemMonitor::update,
        SystemMonitor::view,
    )
    .subscription(SystemMonitor::subscription) // Wire the subscription
    .title("System Monitor")
    .run()
}

impl SystemMonitor {
    // ...
    fn subscription(&self) -> Subscription<Message> {
        cpu_subscription()
    }
    // ...
}

Now when you launch the application, you’ll see the total CPU usage bar updating in real-time every second!

Step 4: Rendering Per-Core Usage (Layout & Styling)

Now let’s expand the view function to display per-core metrics in a clean grid and color-code the progress bars dynamically depending on the load.

We’ll style the progress bars using iced::Theme:

• < 50.0%: Primary color (usually blue)
• 50.0% - 80.0%: Warning color (yellow/orange)
• > 80.0%: Danger color (red)

use iced::widget::progress_bar::{danger, primary, warning};
use iced::widget::{Column, row};

impl SystemMonitor {
    // ...

    fn view(&self) -> Element<'_, Message> {
        let cpu_stats = self.cpu_stats.clone().unwrap_or_default();

        // Total CPU Usage Layout
        let total_cpu_usage = column![
            text("Total CPU Usage"),
            progress_bar(0.0..=100.0, cpu_stats.total as f32)
                .style(move |theme| core_bar_style(theme, cpu_stats.total))
        ];

        // Gather per-core metrics
        let per_core_values: Vec<(usize, f64)> = cpu_stats
            .per_core
            .iter()
            .enumerate()
            .map(|(i, &u)| (i, u))
            .collect();

        // Render cores in rows of 4
        let per_core_rows: Vec<Element<Message>> = per_core_values
            .chunks(4)
            .map(|chunk| {
                let bars: Vec<Element<Message>> = chunk
                    .iter()
                    .map(|(i, usage)| {
                        let usage_val = *usage;
                        column![
                            text!("Core {i}"),
                            progress_bar(0.0..=100.0, usage_val as f32)
                                .style(move |theme| core_bar_style(theme, usage_val))
                        ]
                        .width(Fill)
                        .into()
                    })
                    .collect();
                row(bars).spacing(10).into()
            })
            .collect();

        let per_core_grid = Column::with_children(per_core_rows).spacing(10);

        column![total_cpu_usage, per_core_grid]
            .spacing(10)
            .padding(10)
            .into()
    }
}

// Helper function to color the progress bar based on utilization
fn core_bar_style(theme: &Theme, usage: f64) -> progress_bar::Style {
    if usage < 50.0 {
        primary(theme)
    } else if usage < 80.0 {
        warning(theme)
    } else {
        danger(theme)
    }
}

We now have a fully functioning, beautiful system monitor running entirely natively in Rust.

Gotchas and Tips

Closing

Developing desktop apps in Rust using iced feels like a breath of fresh air. The Elm Architecture brings structure to the traditionally chaotic world of GUI programming, and Subscription makes handling real-time, asynchronous events incredibly elegant.

libcosmic and the COSMIC Desktop

This architecture isn’t just for small utilities: it is the foundation of a complete desktop environment. System76’s COSMIC DE is built entirely on libcosmic, which is a custom widget toolkit built on top of iced.

libcosmic extends iced by providing the styling systems, animations, and specialized widgets (like panels, sidebars, and dialog structures) needed for a cohesive desktop. But under the hood, the core remains pure iced. The way you manage state, handle updates, and spawn background tasks with subscriptions is exactly the same whether you’re writing this basic system monitor or implementing a major system component like the print dialog.

As I continue working on the COSMIC print dialog, I’m constantly surprised by how far the Rust desktop ecosystem has come. If you’re looking to build native desktop applications, give iced a shot.

If you want to expand this app, I have code for parsing other system metrics (like network, memory, and disk) in one of my other projects - Raven under the proc_reader module (btw, the cpu.rs module was pulled from there! :P). Feel free to peek at those implementations, pull them into this system monitor, and experiment with building a more full-featured dashboard.

The complete code for this tutorial’s CPU monitor is available on my GitHub. Give it a spin, and let me know what you think!

…
